54
PARTS LIST - 01708
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Base WD02-00329 34. Lock handle WD02-00352
2. Column flange WD02-00330 35. Label WD02-00353
3. Spring washer M10 WD01-00795 36. Connection WD02-00354
4. Bolt (M10 x 35) WD02-00331 37. Pinion shaft WD02-00355
5. Crank handle WD02-00332 38. Indicator WD01-00897
6. Bolt (M6 x 12) WD01-00905 39. Screw WD02-00356
7. Circlip WD01-00742 40. Roll pin (5 x 25) WD01-00869
8. Worm shaft WD02-00333 41. Screw (M10 x 10) WD02-00345
9. Table support WD02-00334 42. Bearing 6005 WD01-00889
10. Worm pin WD02-00335 43. Warning label WD01-00685
11. Table WD02-00431 44. Roll pin (6 x 18) WD01-00760
12. Spring washer M20 WD02-00337 45. Belt tension handle WD02-00358
13. Bolt (M20 x 55) WD02-00338 46. Lock handle WD02-00359
14. Indicator WD01-00897 47. Circlip WD01-00816
15. Lock handle WD02-00339 48. Circlip WD01-00871
16. Angle label WD02-00340 49. Adjusting shaft WD01-00872
17. Worm gear WD02-00341 50. Shaft WD02-00360
18. Column WD02-00342 51. Washer M12 WD01-00819
19. Rack WD02-00343 52. Washer M10 WD02-00361
20. Hex. wrench 3mm WD01-00790 53. Nut M8 WD01-00687
21. Hex. wrench 4mm WD01-00737 54. Motor plate WD02-00362
22. Screw (M10 x 10) WD02-00345 55. Bolt (M8 x 30) WD02-00363
23. Hex. wrench M5 WD02-00397 56. Spring washer M12 WD01-00676
24. Hex. wrench M6 WD01-00861 57. Nut M12 WD01-00821
25. Rack collar WD02-00346 58. Motor WD02-00428
26. Screw (M6 x 12) WD01-00740 59. Grub screw (M8 x 10) WD01-00689
27. Handle knob WD02-00347 60. Motor pulley WD02-00365
28. Screw (M6 x 12) WD01-00740 61. Motor pulley key WD02-00366
29. Handle cap WD02-00349 62. Nut M10 WD01-00717
30. Screw (M8 x 20) WD01-00801 63. Belt A787 WD02-00367
31. Spring washer M8 WD01-00673 64. Microswitch WD01-00706
32. Handle WD02-00350 65. Washer M5 WD01-00881
33. Scale WD02-00351 66. Spring washer M5 WD01-00882
7
Remove the key from the chuck after adjustment.
Use only the chuck key provided by the manufacturer or a duplicate of it.
Appropriate personal protective equipment MUST be worn and MUST be designed
to protect against all hazards created. Severe permanent injury can result from
using inappropriate or insufficient protective equipment - Eyes in particular are at
risk.
Do not overload the tool. Allow the tool to operate at its optimum speed for maxi-
mum efficiency.
Always ensure that the accessories such as drill bits, as well as the drill are rated /
designed for use with required application, and are the bits are correctly and se-
curely fastened before connecting the tool to the mains supply.
The work must be clamped firmly while drilling. Any tilting, twisting or shifting results
not only in a rough hole but also increases the hazard, which could result in injury or
drill breakage. For flat work lay the piece on a wooden base and clamp it firmly
down against the table to prevent it from turning If the piece is of irregular shape
and cannot be laid flat on the table, it should be securely blocked and clamped.
Understand the operating environment; Before each use the operator should as-
sess, understand and where possible reduce the specific risks and dangers associ-
ated with the operating environment. Bystanders should also be made aware of
any risks associated with the operating environment.
SAFETY INSTRUCTIONS….cont
When using the pillar drill for certain operations, particularly during ex-
tended periods; ensure the operator as well as those in the area wear
ear protection.
When using the pillar drill always ensure the operator as well as those in
the area wear eye protection.
Some materials have the potential to be highly toxic; always wear a
face mask when operating the pillar drill.
CAUTION: The warnings and cautions mentioned in this user manual can not cover all possible
conditions and situations that may occur. It must be understood by the operator that common
sense and caution are factors which cannot be built into this product, but must be applied.
