52
PARTS LIST - 01707….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
69. Washer M6 WD01-00702 94. Screw (M6 x 12) WD02-00381
70. Spring washer M6 WD01-00707 95. Screw (10 x25) WD02-00382
71. Nut M6 WD01-00710 96. Casting WD02-00383
72. Cam assembly WD02-00368 97. Spindle pulley WD02-00384
73. Screw (M5 x 16) WD01-00838 98. Key WD02-00385
74. Washer WD01-00881 99. Spindle shaft WD02-00386
75. Protecting ring WD01-00839 100. Bearing 6007 WD02-00387
76. Pulley cover WD02-00369 101. Ring WD02-00388
77. Washer M8 WD01-00672 102. Circlip WD02-00389
78. Bolt (M8 x 10) WD02-00370 103. Switch box WD02-00390
79. Clamp WD02-00371 104. Switch WD01-00895
80. Circlip WD02-00372 105. Screw (ST3.2 x 12) WD02-00391
81. Knurled screw WD02-00373 106. Washer WD02-00392
82. Eccentric shaft WD02-00374 107. Quill WD02-00393
83. Centre pulley WD02-00375 108. Bearing 51107 WD02-00394
84. Bearing 6202 WD01-00771 109. Spindle WD02-00395
85. Circlip WD01-00831 110. Arbor MT4 17823
86. Belt A686 WD02-00376 111. Chuck WD02-00396
87. Protecting ring WD01-00770 112. Chuck guard 75mm 68328
88. Clamp WD02-00377 113. Drift key WD01-00862
89. Mains lead WD01-00720 114. Hex. wrench 3mm WD01-00790
90. Tension spring WD02-00378 115. Hex. wrench 4mm WD01-00737
91. Tension spring cover WD02-00379 116. Hex. wrench 5mm WD02-00397
92. Nut WD02-00380 117. Hex. wrench 6mm WD01-00861
93. Washer M6 WD01-00702
9
TECHNICAL SPECIFICATIONS….cont
Part number 01703 01704 01705
Model B20-16 F16-16 F20-16
Input Voltage 230v ~ 50hz 230v ~ 50hz 230v ~ 50hz
Power 550 w 375 w 550 w
Speed Range 180-2770 rpm 180-2770 rpm 180-2770 rpm
Number of Speeds 16 16 16
Drill Bit Size 3-16 mm 3-16 mm 3-16 mm
Max. Drilling Capacity (mild Steel) 16 mm 16 mm 16 mm
Spindle Taper MT2 MT2 MT2
Table Size 290 x 290 mm 250 x 250 mm 290 x 290 mm
Base Size 462 x 274 mm 450 x 265 mm 450 x 265 mm
Column Ø 72 mm 72 mm 72 mm
Swing 360 mm 325 mm 360 mm
Height 990 mm 1550 mm 1565 mm
Spindle Travel 83 mm 80 mm 83 mm
Collar Ø 55 mm 55 mm 55 mm
Max. Distance Chuck to Table 405 mm 725 mm 682 mm
Max. Distance Chuck to Base 600 mm 1205 mm 1174 mm
Net Weight 50 Kg 47 Kg 53 Kg
Gross Weight 52 Kg 50 Kg 57 Kg
