Sirona C3+ - Dimensions of the C3 + 1:20

2 Dimensions, technical data Sirona Dental Systems GmbH
Installation Requirements C3
+
, C4
+
, C4
+
Cart
60 27 945 D3382
18 D3382.021.02.12.02
2.1 Dimensions of the C3
+
1:20
Hazard warning:
The here mounted lamp, the dentist element /
with tray (option) and the assistant element
with long support arm have a wider swivelling
range than the distances indicated!
Recommended distances
from cabinet or wall.
Center floor opening
250
9 7/8”
1200
47 1/4”
1300
51 3/16”
2500
98 7/16”
300
11 3/4”
