Sirona C3+ - Dimensions of the C4 + 1:20

Sirona Dental Systems GmbH 2 Dimensions, technical data
Installation Requirements C3
+
, C4
+
, C4
+
Cart
60 27 945 D3382
D3382.021.02.12.02
21
båÖäáëÜ
2.2 Dimensions of the C4
+
1:20
250
9 7/8”
** 1450 -1700
57" - 67”
1300
51 3/16”
2500
98 7/16”
* 160 - 450
6 1/4" - 17 3/4”
** Depending on setting of support arm
Recommended distances
from cabinet or wall.
Hazard warning:
The lamp installed here has a swivel
range which exceeds the specified
distances!
Center floor opening
* Depending on the setting of the support arm stop (factory setting: 450mm)
