Sirona Dental Systems GmbH 2 Dimensions, technical data
Installation Requirements C8
+
2.6 C8
+
Turn 1:20
60 28 000 D3417
D3417.021.04.09.02
29
Minimum clearances for conversion of treatment center from
right-handed to left-handed version an vice versa 2700x2650mm
C8
+
Turn 1:20
Center floor opening
1050
41 3/8”
1050
41 3/8”
2750
108 1/4”
1600
63”
1234
48 1/2”
1600
63”
Cabinet right or left max.
900mm height
250
9 7/8”
250
9 7/8”
