2 Dimensions, technical data Sirona Dental Systems GmbH
2.6 C8
+
Tu r n 1 : 2 0 Installation Requirements C8
+
60 28 000 D3417
30 D3417.021.04.09.02
Minimum clearances for conversion of treatment center from
right-handed to left-handed version an vice versa 3650x2100mm
C8
+
Turn 1:20
1050
41 3/8”
1050
41 3/8”
Center floor opening
3650
143 3/4”
2134
84”
1250
49 1/4”
Storage space
max. 900mm height
250
9 7/8”
250
9 7/8”
