- 26 -
ACCESSORIES ( OPTIONAL)
ELASTIC FOOT: SP-750420006
This special sewing foot is for sewing on elastic tape. In the same operation, the fabric is trimmed,
serged and gathered by the constriction of the elastic tape.
Loosen screw (2) so that brake (1) at opening (4) is opened by 1.5 to 2mm.
Place in elastic tape (3) and pass it back under the foot.
Tighten brake (1) with screw (2) again, the more screw (2) is turned, the stronger the pressure of
brake (1) on the elastic tape and thus the greater the gather effect.
Note:
When the sewing foot is raised, the elastic tape should be pulled through brake (1) slightly braked.
Preparing the machine
Differential feed setting: Set at “N” position
Stitch length: Approx
Needles: Use 1 or 2 needles, depending on tape width
Thread tension: Standard setting
Tighten Loosen
2
1
3
4
Elastic
