Description for LED indicators
LED Power Link Status Remark
Booting Flash Flash
System Ready On Off
LAN connected On On
Data transferring On Quick Flash
Activate WPS, push
button for less than
5 sec.
On Slow Flash The configuration should be
finished within 120 sec., after that
the Link Status LED will go back to
the original status
Reset to default,
push button for
longer than 10 sec.
Quick Flash On 2 LEDs will turn off when reset to
default is taken effect then system
will start booting
Power LED
