SKF CMAS100-SL User Manual

SKF Machine Condition Advisor 19
User Manual
¾ Use of the instrument’s optional
external sensor affects battery life.
An external sensor kit (CMAC105) is available for the
Machine Condition Advisor. The kit consists of:
A 100 mV/g accelerometer sensor with integral
cable (CMAC104), and
A magnet attachment (CMAC106) for the
accelerometer.
To connect the external sensor:
• Screw in and tighten the magnet to the external
accelerometer sensor.
• On the external sensor’s cable, locate the two
alignment guides on the connector’s green
strain relief. Identify the alignment guide that is
in line with the connector’s keyway (you may
wish to mark the appropriate alignment guide
with a felt tip marker for easy future
identification).
• On the MCA’s connector, locate the small notch
into which the cable connector’s keyway fits.
Note that the notch is aligned with the MCA
case’s seam.

SKF CMAS100-SL Specifications

General

Brand	SKF
Model	CMAS100-SL
Category	Diagnostic Equipment
Language	English
