• Read and understand entire instruction manual before installing or servicing of SFD
• SFD dryer systems not designed for use other that removal of water from compressed air
• SFD dryer systems cannot be used for breathable air
• Never connect or disconnect a pipe/line containing air pressure or remove a component, fitting or pipe
plug unless you are certain all air pressure has been shut off and relieved
• Always wear proper eye protection and never look directly into ports of SFD
• Sound decibels without silencer @ 120 db / with silencer @ 37db
• Never exceed recommended working air pressure of 190 psi/13.1 bar
• A by-pass system recommended making servicing of SFD dryer units easier and safer
• Use only proper tools and observe all precautions pertaining to the use of those tools
GENERAL MOUNTING INSTRUCTIONS:
• Allow 2” min above cartridges for cartridge removal
• Air line routing and connections may be modified to accommodate space and application
• All air line connections require thread sealant
• Aluminum threads require an anti-seize compound (included within SFD dryer service kits)
• Optional thermostatically - controlled heaters available for MLT and PLC dryer systems
• SFD dryer systems must be mounted with the exhaust ports positioned downward and desiccant
cartridges in upright position
• Mount SFD utilizing 3/8” grade 5 bolts, washers, lock washers and nuts are recommended and not
furnished with air dryer kits
• Manifold design may be either square or round
• Plug electrical connection to dedicated and accessible wall receptacle
• Electrical cord replacement only with timer and coil only – cord and plug not serviced separately
WARNING
Read, understand and follow safety precautions and instructions in this manual and
in the labels attached to the dryer system. Failure to do so could result in serious
injury, death and property damage.
