SERVICE COMPONENTS
Micro Logic Timer (MLT) Applications (5 – 120 CFM Dryer Systems)
1. Identify dryer system by counting numbers of desiccant cartridges, e.g., 2, 4, 6
2. Locate service component identity, e.g., A, B, C, etc.
3. Under “QTY”, order appropriate number of kits specific to cartridge totals
2 4 6
Illustration
ref.
Part
Number
Qty Qty Qty Descriptions
619000 1 2 3
SFD "O" Ring/Gasket Kit
A 619705 1 - -
Internal Purge 2 lb. Desiccant Cartridge Kit
A, F 619710 1 2 3
4 lb. Desiccant Cartridge Kit
A,D,I,J
619700 1 2 3
Full Service Kit - (2) 4 lb cartridges, 2 inlet check valves, 2 purge
valves, 1 outlet check valve
A 619667 1 2 3
8 lb. Desiccant Cartridge Kit
A,F 619704 1 2 3
4 lb. Desiccant Cartridge Kit
619734 1 2 3
Right hand adaptor plate with stud
619735 1 2 3
Left hand adaptor plate with stud
C 619708 2 - -
Regeneration Valve Kit (includes 2 .016)
C 619715 2 4 6
Regeneration Valve Kit (includes 2 .030)
D,I,J
619702 1 2 3
Valve Service Kit - includes 2 inlet check valves, 2 purge valves, 1
outlet check valve
E 619755 1 - -
Air Control Valve - Three air lines
E
619925 1 - - Air Control Valve - Two air lines
619020 1 - - Max 20 cfm prefilter coalescer complete assembly
619081 1 1 Max 80 cfm prefilter coalescer complete assembly
619160 - - 1 Max120 cfm prefilter coalescer complete assembly
619245 1 1 1 Max 200 cfm oil coalescing .01 prefilter w/pneumatic drain service kit
619246 1 - - Max 20 cfm oil coalescing .01 prefilter w/pneumatic drain service kit
619860 1 2 3
Integrated filter kit
619790 1 1 1
110 Volt Timer
619792 1 1 1 12 VDC Timer
619794 1 1 1 24 VDC Timer
Not Shown 619935 1 2 3
MLT/Heater Wire Harness
H 619740 1 2 3
Pressure Relief Valve
J 619701 1 2 3
Inlet Check Valve Kit - Includes 2 inlet check valves
K 619772 2 4 6
Muffler
619750 1 2 3
110 Volt Heater Kit (optional)
619782 1 - - 12 VDC Heater Kit (optional)
619784 1 - -
24 VDC Heater Kit (optional)
M 619990 1 2 3 Wall Mounting Bracket
N
619995 1 - - Universal Mount Bracket
Not Shown 619775 1 1 1 Moisture Minder (optional)
O 619917 - 4 6
Manifold Retaining Bolt
P 619780 - 1 -
Manifold/Mounting - two dryers (4 cartridges)
P 619785 - - 1
Manifold/Mounting - three dryers (6 cartridges)
Not Shown 619942 1 - - Wall Strut single unit
Not Shown 619926 1 1 - Regneration cut off kit
G
F
L
Cartridges
Dryer Systems with
B
