Skipper ESN200 - Default Chapter; Table of Contents

Page 3 of 61
SKIPPER Electronics AS
Edition: 2021.02.17
ESN200 Operation and Installation Manual
Contents
INTRODUCTION 4
Specication 6
MECHANICAL INSTALLATION 7
InstallationDetails 8
CONFIG SOFTWARE SETUP 11
ES Setup 12
Transducersetup 12
Mainsetup 15
Options 16
Options:Synchronisedpinging 17
CommunicationsSetup(NMEA) 18
AcceptedNMEAinputs 21
AUXSetup 22
RuntimeScreenSetup 25
Displaysetup 29
Screensetup 29
Remotedimmingsetup 30
Alertsetup 31
ConnectionbetweenJB70E2andDisplayunits 35
Servicesoftware 35
DisplayUnitsetup–Networksettings 35
JB70setup 36
Printing 38
Printers 38
SetupprintbuttoninRuntimeScreen 38
Setupprintertypein“PrintSetup”menu 38
Connectingtheprinter 39
Networkprinting 39
PCconnectionSetup 40
Upgradingsoftware 41
USERINFORMATION 42
Introduction 42
AutoFunctions 44
Manualmode 44
ScreenConguration 45
24HoursHistory 48
Extendedloggingofhistory 49
DIAGNOSTICS 51
APPENDIX1:INSTALLATIONDRAWINGS 55
ENS518-SATransducerselector 58
Tableofabbreviations 60
