Skipper ESN200 - Page 59

Page 59 of 61
SKIPPER Electronics AS
Edition: 2021.02.17
ESN200 Operation and Installation Manual
Chapter: Appendix 1: Installation drawings
96 3,780
96
3,780
46 1,811
60,9 2,398
82
3,228
60 2,362
70 2,756
1
1
1
ENS518
E/S
FORE
AFT
TRANSDUCER SELECTOR
FORE
AFT
SCR
FEEDB
Turned 180°
Nut M4
Tab size 6.3 x 0.8
Washer DIN 6797 Form A (2x)
Stud M4 x 12
Drilling holes
4.5 (0.177)
ENS518
TRANSDUCER SELECTOR
FORE
AFT
RAL 9005
RAL 9005
RAL 9005
ZOA-01171
Nitril O-Ring Ø110 X 2,50mm
ZOA-01172 (x4)
Lock nut M4 DIN985 A4
ZOA-01172 (x4)
Lock nut M4 DIN985 A4
Revision
12-030 HK
2012.10.09
ISO2768m
Gen. tolerance Eur. projection
Material
Electronics AS
Checked by
CN
Drwg. no.
Name
GT 2013.11.18
Edition date
Sheet
1140A
ENS518-SA
Scale
Drawing ENS518-SA
Transducer Selector Panel
1 of 1
Designed by - date
GT
ST 2013.11.18
Approved by - date
F
E
D
A
B
4 1 3 2
C
