Changing light bulbs for fog lights
Fig. 195 Remove the number plate light / replace the bulb
Read and observe and on page 156 first.
Remove the protective grille and headlight
›
Insert the clamps for removing the full wheel trims into opening
A
» Fig. 195.
›
Pull the hook in the direction of arrow
1
to remove the protective grille in
the direction of arrow
2
» Fig. 195.
›
Unscrew the screws
B
with the screwdriver from the tool kit.
›
With the key
2
» page 141, Vehicle tool kit, unlock the locking
C
in direction
of arrow
3
.
›
Remove the headlight in the direction of arrow
4
.
Replacing the light bulb
›
Press the latch on the connector in the direction of arrow
5
.
›
Remove the key in the direction of the arrow
6
.
›
Turn the socket with the bulb to the stop in the direction of the arrow
7
.
›
Remove the socket with the bulb in the direction of arrow
8
.
›
Insert the new bulb into the headlight and turn counter to the direction of
arrow
7
as far as the stop.
›
Attach the connector.
Refit the headlight and grille
›
Replace the fog light by inserting it in the opposite direction of the arrow
4
» Fig. 195 and tightening.
›
Insert the guard and push it gently until it locks into place.
Changing the bulb for the licence plate light
Fig. 196
Remove / replace the bulb for the number plate light
Read and observe and on page 156 first.
›
Push the light in the direction of arrow
1
» Fig. 196 until it comes loose.
›
Swivel out the lamp in the direction of the arrow
2
and remove it.
›
Remove the faulty bulb from the holder in the direction of the arrow
3
.
›
Insert a new bulb into the holder.
›
Reinsert the lamp in the opposite direction to the arrow
1
.
›
Push on the light until the spring clicks into place.
159
Fuses and light bulbs
