SKS-Kinkel Elektronik GmbH
Indoor station HTV4600, Receiver, 6-wire
EN
Support Hotline: +49 (0) 2661 98088-112
Support E-Mail: support@sks-kinkel.de
Version No. 3.0
Document No. 97003704
28
1 Installation instructions
IMPORTANT!
READ CAREFULLY BEFORE USE!
KEEP FOR FUTURE REFERENCE!
2 Description
The HTV4600 indoor station is able to communicate with SKS door stations and other SKS indoor stations, a door can
be unlocked and certain special functions can be controlled.
This manual apply to the following SKS items:
✓ HTV4600 with 6 buttons (items 10003901, 10004101, 10004001)
✓ HTV4600 with 11 buttons (items 10003201, 10003301, 10003001, 10003101 )
2.1 Contractual use
3 Optical and acoustic signalling of door calls, oor calls and internal calls
3 Accept calls using the receiver
3 Open the door
3 Switch on light (only with an additional switching actor)
3 Use only indoors in places free from dripping or spraying water
2.2 Features
3 SKS BUS technology
3 Key functions: Opening door, adjusting volume of calls and ringtones, switching o ringtone (ringtone is reac-
tivated automatically after 12 hours), adjusting colour, contrast and brightness
3 Switching functions possible (without additional wires, via switching actor 300022)
3 Automatic activation of TFT colour display when door call comes in
3 Optical signalling of calls by LED
3 Receiver is held by a magnet (allows for an optimal operability at any age)
3 Audio and video privacy function
3 One-man installation and programming
3 Parallel operation of up to 3 indoor stations optional
3 8 door call- and 4 oor call ringtones
3 Ringtone volume can be adjusted in 5 steps
3 Optional 5 additional keys for internal communication
3 Surface-mounted
2.3 Scope of Delivery
3 Indoor station HTV4600 incl. receiver
3 Receiver cable
3 Instruction manual
