Step Image Description
2
Keep hold of the programming button at the back of the device for ve
seconds until you hear a signalling tone.
After this signalling tone another, shorter tone will be played signalling
that programming the rst call address has been successful (storage
location no. 1).
3
B1
Set the DIP switch to the internal receiving address (= 2nd position in your
storage space, in the example above B1), which responds to internal
calls sent to the indoor station.
4
Keep hold of the programming button at the back of the device for ve
seconds until you hear a signalling tone.
After this signal tone another two shorter tones are audible when the
second call address is programmed to indicate that this call address has
been saved in the second internal storage location.
5
B2
Set the internal call address (= internal call address of indoor station
2, saved on rst internal call key, in the example above B2) at the DIP
switch. This will be called by indoor station 1 when the respective key is
operated.
6
+
1
Keep hold of the programming button on the back of the device and also
keep hold of key 1 within two seconds. Hold both keys at the same time
for ve seconds until a signal tone is heard. Thus key 1 is assigned inter-
nal call address B2, i. e. if key 1 is pushed, indoor station 2 will be called.
7
B3
Set the DIP switch to the internal call address (= internal call address of
indoor station 3, saved on the internal call key 2, in the example above
B3), this will be called by pushing the respective bell button at the door
station.
8
+
2
Keep hold of the programming button at the back of the device and, with-
in two seconds, also keep hold of the key 2. Keep hold of both keys for
ve seconds until you hear a signal sound. Thus key 2 has is assigned
the internal call address B3, i. e. Sif key 2 is pushed, station 3 will be
called.
Attention
We recommend setting the DIP switch back to the main call address (= rst call ad-
dress programmed) after the programming is nished, so that it can easily be recog-
nized which bell button belongs to which indoor station in case of a breakdown..
After programming the rst indoor station go on programming indoor stations 2 and 3 in the same way.
