Section 2 – Maintenance Tables and Diagrams Floor Loading Pressure (CE)
2.14 Floor Loading Pressure (CE)Table
Model
Weights Pressures
MEWP
weight
Max weight
per wheel
LCP** OFL**
kg kg kPa kPa
3220
min* 1967 495 562 10.7
max* 2375 853 749 12.9
3226
min* 2014 503 567 10.9
max* 2241 794 718 12.2
4720
min* 2040 510 570 7.7
max* 2630 934 790 9.9
4726
min* 2135 534 583 8.1
max* 2589 1066 856 9.8
4732
min* 2600 650 644 9.8
max* 2917 1066 856 11.0
* Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max: Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform
** LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the oor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath the
chassis. This has been calculated by dividing the MEWP weight by the overall oor area occupied by the MEWP (on wheels).
Note: The oor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above
Note: The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure
