41
SJ3220, SJ3226, SJ4720, SJ4726, SJ4732 223198ABA
Floor Loading Pressure (AS) Section 2 – Maintenance Tables and Diagrams
Model
MEWP weight
Max weight per
wheel
LCP** OFL**
kg kg kPa kPa
SJ3220
Min* 1776 445 536 9.6
Max* 2184 853 749 11.9
SJ3226
Min* 1900 475 552 10.3
Max* 2127 794 718 11.5
SJ4726
Min* 2135 534 583 8.1
Max* 2589 1066 856 9.8
SJ4732
Min* 2492 623 630 9.4
Max* 2809 1066 856 10.6
* Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max: Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform
** LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the oor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath the
chassis. This has been calculated by dividing the MEWP weight by the overall oor area occupied by the MEWP (on wheels).
Note: The oor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above
Note: The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure
2.15 Floor Loading Pressure (AS)Table
