Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 125
6.2 Axle Hardware
Index
No.
Skyjack
Part No.
Qty. Description
1 159289 2 PLATE, Wear pad
2 152324 4 BOLT, Hex head (M12 x 1.75 x 25mm, Grade 8.8)
3 104379 4 WASHER, Flat hardened (1/2”)
4 146773 4 BOLT, Hex head (3/4”-10 x 5”, Grade 8)
5 702194 8 WASHER, Flat hardened (3/4”)
6 700575 8 NUT, Torque lock (3/4”-10, Grade C)
7 152304 2 FITTING, Straight (08 JICM - M18 DIN 3852-1)
8 706812 2 FITTING, Straight (08 JICF - 04 JICM)
9 148866 2 U-BOLT, Axle mount
10 144128 1 FITTING, 90° (04 JICM - 04 BSPPM) - serial number 95 002 085 & above
149195 1 FITTING, Straight (04 JICM - 04 BSPPM) - serial number 95 002 084 & below
11 149181 1 FITTING, Straight (06 JICM - M14 ISO6149)
12 139126 1 SEAL, British bonded (04BSPPM)
13 152333 1 CLAMP, Tube (5/8” cus double 17/32 hole)
14 103909 1 BOLT, Hex head (1/2”-13 x 1.25”, Grade 5)
15 (Ref.) - OIL
(For components, refer to Section 11.1)
16 (Ref.) - GREASE
(For components, refer to Section 11.3)
17 702875 1 FITTING, Straight (04JICM-04JICFS) - serial number 95 002 085 & above
To Next Page
