Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 47
3.0 CYLINDERS
3
3.6
Slave
Cylinder
3.7
Jib Cylinder
3.3
Riser Cylinder
Mounting
3.2
Main Boom
Lift Cylinder
3.5
Master Cylinder
3.1
Extension Cylinder
3.8
Axle Lock Cylinder
3.4
Riser Lift
