Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 19
1.7 Platform Control Console
AD
Index
No.
Skyjack
Part No.
Qty. Description
A 162381 - PLATFORM CONTROL CONSOLE ASSY (46AJ ANSI/CSA - Deutz)
B 170008 - PLATFORM CONTROL CONSOLE ASSY (46AJ/51AJ CE - Deutz)
C 167523 - PLATFORM CONTROL CONSOLE ASSY (46AJ/51AJ AS - Deutz)
D 162478 - PLATFORM CONTROL CONSOLE ASSY (46AJ ANSI/CSA - GM & Kubota)
1 154122 1 • CONTROL BOX, Platform
154123 1 • • BODY, Control box
154124 1 • • LID, Control box
149384 1 • • HINGE, Nylon (Left hand)
149385 1 • • HINGE, Nylon (Right hand)
138715 2 • • LATCH, Slotted door
138334 1 • • WEATHER STRIP, Cut
159879 2 • • STUD, Aluminum (#10-32 x 3/8”)
103959 8 • • SCREW, Round head machine (#10-24 x 1/4”)
163512 8 • • WASHER, Lock (#10)
2 (Ref.) - • CONTROLLER, Drive / Steer
(For components, refer to Section 1.9)
3 (Ref.) - • CONTROLLER, Boom / Turret
(For components, refer to Section 1.8)
4 (Ref.) - • CONTROLLER, Riser
(For components, refer to Section 1.10)
5 124446 1 • SWITCH, Toggle (2NT1-50)
6 115747 1 • SWITCH, Toggle (1NT1-3)
7 115574 1 • SWITCH, Toggle (1NT1-2), A, B, C
2 • SWITCH, Toggle (1NT1-2), D
8 148988 1 • SWITCH, Toggle (2NT1-70)
9 138278 4 • SWITCH, Toggle (2NT1-7)
10 138278 1 • SWITCH, Toggle (2NT1-7), A, D
138279 1 • SWITCH, Toggle (2NT1-7E), B, C
11 144016 9 • PANEL BUSHING SEAL, A, B, C
10 • PANEL BUSHING SEAL, D
12 148971 1 • LIGHT, Pilot (Amber)
13 144648 1 • SWITCH ASSEMBLY, HORN PUSHBUTTON
147056 1 • • LATCH, Mounting
147054 1 • • BLOCK, NO Contact
147058 1 • • SWITCH HEAD, Horn pushbutton
14 144647 1 • SWITCH ASSEMBLY, PLATFORM E-STOP
147056 1 • • LATCH, Mounting
147229 1 • • SWITCH, LED Block (Red)
147053 2 • • BLOCK, NC Contact
147051 1 • • SWITCH HEAD, Emergency stop
15 138229 1 • MODULE, Upper indicating
139203 6 • • BULB, 12V
Parts list continued on the following page.
