Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 219
9.7 Arctic Package Option
Index
No.
Skyjack
Part No.
Qty. Description
A 167857 - ARCTIC PACKAGE OPTION (ANSI/CSA - GM)
B 167854 - ARCTIC PACKAGE OPTION (ANSI/CSA - Deutz D2011)
C 167860 - ARCTIC PACKAGE OPTION (ANSI/CSA - Deutz D2.9L)
D 171132 - ARCTIC PACKAGE OPTION (ANSI/CSA - Kubota WG2503)
1 703290 1 • BLANKET, Battery
2 159888 1 • CORD, “W”
3 164762 1 • HEATER, Pad - 500W
4 144727 2 • TIEWRAP, Cable (43.3”)
5 152402 2 • CLAMP, Tube (Cushioned)
6 103473 2 • BOLT, Hex head (3/8”-16 x 1.00, grade 5)
7 103472 3 • WASHER, Flat, 3/8”
8 104606 1 • NUT, Hex head nylon lock (3/8”-16, grade 5)
9 144671 1 • HEATER, Block, A
144642 1 • HEATER, Oil pan, B
165559 1 • HEATER, Block, C
170072 1 • HEATER, Block, D
10 166299 1 • CORD, Oil pan heater, B
11 170073 1 • ADAPTER, Block heater, D
12 (Ref.) - • OIL
(For components, refer to Section 11.1)
13 (Ref.) - • COOLANT, Antifreeze
(For components, refer to Section 11.1)
14 (Ref.) 1 • LOAD CIRCUIT MANIFOLD (not shown), C
(For components, refer to Section 9.8)
15 (Ref.) 1 • LOAD CIRCUIT HOSE KIT (not shown), C
(For components, refer to Section 9.9)
L1 144632 1 • LABEL, Hydraulic oil heater/battery warmer (Located on W-Cord)
L2 144633 1 • LABEL, Arctic hydraulic oil (Located on hydraulic tank)
L3 144635 1 • LABEL, Arctic engine oil (Located on oil dipstick), B, C
AB
