Skyjack SJ46AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 237
9.15 Generator & Oil Cooler Assembly - 3.5kW (51AJ)
AB
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
35 170450 1 • SHROUD, Generator - upper
36 170451 1 • SHROUD, Generator - lower
37 137625 45” • SEAL, Bulb
38 101632 4 • BOLT, Hex head (0.375”-16 x 0.75” Grade 5)
39 136665 1 • BOLT, Hex head (M10 x 1.25 x 35mm Grade 8.8)
40 144260 1 • NUT, Hex head nylon lock (M10-1.25 Grade 8.8)
41 127067 4 • WASHER, Flat BB style (0.375”)
42 138981 1 • FITTING, Elbow 90° (10 JICM - 12 ORBM)
L 117390 1 • LABEL, Push to reset generator
