Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 241
9.17 Generator Wiring - 3.5kW
Index
No.
Skyjack
Part No.
Qty. Description
A 169581 1 GENERATOR WIRE KIT - Platform control console
- 169587 1 • WIRE ASSEMBLY, Generator anti-start
1 127131 1 • • RELAY, 12V 40 amp
2 138749 1 • • SOCKET, Relay
3 169477 1 • • WIRE ASSEMBLY, Generator (85)
4 169588 1 • • WIRE ASSEMBLY, Generator (78/85)
5 169479 1 • • WIRE ASSEMBLY, Generator (02)
6 169480 1 • • WIRE ASSEMBLY, Generator (57A)
7 169494 1 • • LABEL, Relay (57ACR1)
8 144081 1 • WIRE ASSEMBLY, Generator (04)
9 144082 1 • WIRE ASSEMBLY, Generator (04A)
10 115747 1 • SWITCH, Toggle (1NT1-3)
11 144016 1 • SEAL, Toggle switch
B 148596 1 GENERATOR WIRE KIT - Generator
12 152582 1 • HARNESS, Generator valve
117597 1 • • CONNECTOR, Plug (2-pin)
117599 1 • • CONNECTOR, Plug wedge (2-pin)
117591 2 • • CONNECTOR, Contact socket (16/18)
13 103024 1 • CLIP, Single (G8)
14 103857 1 • BOLT, Hex head cap (1/4”-20 X 1” Grade 5)
15 103995 1 • WASHER, Flat (1/4”)
16 115649 1 • NUT, Hex lock (1/4”-20 Grade 5, nylon)
AC
To Next Page
