Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 251
9.23 Generator Wiring - 12 kW
Index
No.
Skyjack
Part No.
Qty. Description
A 169999 - WIRE ASSEMBLY, Generator - base control box (46AJ ANSI/CSA)
1 116266 1 • CONNECTOR, Strain relief
2 137940 1 • TERMINAL BLOCK, 4 cond through
3 159938 1 • WIRE ASSEMBLy (85)
4 163093 2 • HARNESS, Generator valve
117597 1 • • PLUG, Connector 2-pin
117599 1 • • WEDGE, Connector plug 2-pin
117591 2 • • SOCKET, Connector contact
5 102921 1 • DIODE 6A
6 137944 1 • LABEL, Terminal
7 113085 1 • MARKER, Wire - Brady
B 169581 1 WIRE KIT, Generator - upper control box (46AJ ANSI/CSA)
- 169587 1 • GENERATOR ANTI-START KIT
7 127131 1 • • RELAY, 12V 40 amp
8 138749 1 • • SOCKET, Relay
9 169477 1 • • WIRE ASSEMBLY (85)
10 169588 1 • • WIRE ASSEMBLY (78/85)
11 169479 1 • • WIRE ASSEMBLY (02)
12 169480 1 • • WIRE ASSEMBLY (57A)
13 169494 1 • • LABEL, Generator anti-start relay 57ACR1
14 137940 1 • • BLOCK, Terminal (4 cond through)
15 137942 1 • • JUMPER, 2-pin
16 144081 1 • WIRE ASSEMBLY, Generator (04)
17 144082 1 • WIRE ASSEMBLY, Generator (04A)
18 115747 1 • SWITCH, Toggle (1NT1-3)
19 144016 1 • SEAL, Toggle switch
To Next Page
