Skyjack SJ46AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 43
2.6 Jib Boom Assembly
Index
No.
Skyjack
Part No.
Qty. Description
- 167645 - JIB BOOM ASSEMBLY
1 (Ref.) - • JIB CYLINDER ASSEMBLY
(For components, refer to Section 3.7)
2 148876 1 • BRACKET, Jib mount
3 148881 1 • WELDMENT, Lower arm
4 167648 1 • WELDMENT, Upper arm
5 148891 1 • COVER, Hose
6 167659 1 • BRACKET, Platform mount
7 146897 6 • KEEPER PIN (3/8”)
8 148890 6 • PIN (1 1/4” diameter x 10 3/16”)
9 143987 2 • CLAMP (2 1/2”)
10 148847 8 • BUSHING (1 1/4” ID x 1”)
11 125262 8 • BUSHING (1 1/4” ID x 1 1/2”)
12 148920 2 • SPACER
13 148936 1 • PAD, Wear
14 148943 6 • BOLT, Hex head patch (5/16”-18 x 1” Grade 8)
15 103996 8 • WASHER, Flat (5/16”)
16 300064 2 • SCREW, Button head cap (5/16”-18 x 3/4”)
17 103984 2 • NUT, Hex lock (5/16”-18 Grade 5, nylon)
18 103856 4 • BOLT, Hex head (1/4”-20 x 3/4” Grade 5)
19 103995 4 • WASHER, Flat (1/4”)
