Skyjack SJ46AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 65
4.3 Cowling Assembly - Controls Side
Index
No.
Skyjack
Part No.
Qty. Description
- 148614 1 COWLING ASSEMBLY, CONTROLS SIDE
- 149260 1 • COWLING, Assembly (Controls Side)
1 149262 1 • • COWLING, Shell (Controls Side)
2 160204 1 • • WELDMENT, Cowling frame (Controls Side)
3 125959 4 • • WASHER, Flat hardened (3/8”)
4 127067 4 • • WASHER, Flat (3/8” Style BB)
5 101297 4 • • BOLT, Hex head (3/8”-16 x 1 1/4” Grade 5)
6 104606 4 • • NUT, Hex lock (3/8”-16 Grade 5, nylon)
7 149483 2 • WELDMENT, Hinge lower LHS
8 144002 1 • LATCH, Flexible draw
9 146903 2 • STUD, Ball (10mm)
10 103984 2 • NUT, Hex lock (5/16”-18 Grade 5, nylon)
11 126642 4 • NUT, Hex lock (#10-24 Grade 5, nylon)
12 104694 2 • WASHER, Flat (#10)
13 138834 4 • SCREW, Round machine (#10-24 x 3/4”)
14 152431 1 • GAS SPRING, Cowling
15 125959 6 • WASHER, Flat hardened (3/8”)
16 103473 6 • BOLT, Hex head (3/8”-16 x 1” Grade 5)
17 138736 2 • BOLT, Hex head (3/8”-16 x 6” Grade 5)
18 104606 2 • NUT, Hex lock (3/8”-16 Grade 5, nylon)
19 149333 1 • WELDMENT, Latch mount
20 149334 1 • WELDMENT, Cowling bumper
21 144015 2 • MOUNT, Anti-vibration
22 103980 2 • NUT, Hex head (1/4”-20 Grade 8)
23 103995 3 • WASHER, Flat (1/4”)
24 103857 3 • BOLT, Hex head (1/4”-20 x 1” Grade 5)
