Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 75
4.8 Brake Manifold (serial number 95 001 717 and above)
AD
Index
No.
Skyjack
Part No.
Qty. Description
- 195803 - BRAKE MANIFOLD ASSEMBLY (serial number 95 001 717 and above)
- 168642 1 • MANIFOLD, Brake
1 171413 1 • • VALVE, Check
2 166053 1 • • VALVE, Shuttle
3 166054 1 • • VALVE, Shuttle
4 171420 1 • • ORIFICE, Disc (0.073”)
5 168754 1 • • VALVE, Pressure reducer
6 159827 4 • • VALVE, Solenoid
7 159831 1 • • PUMP, Hand
8 141414 1 • • VALVE, Shuttle
9 141436 1 • • VALVE, Brake release override
10 114578 1 • FITTING, 90° elbow (06 JICM - 06 ORBM)
11 701956 2 • FITTING, Straight (04 JICM - 06 ORBM)
12 125883 1 • FITTING, 90° elbow (04 JICM - 04 ORBM)
13 103069 1 • FITTING, Straight (06 JICM - 06 ORBM)
14 128869 2 • FITTING, Straight (06 JICM - 04 ORBM)
15 113348 1 • FITTING, 90° elbow (06 JICM - 04 ORBM)
16 121250 1 • FITTING, Plug (04 ORB hex socket)
