August 2007
SKYJACK, Page 38
Section 2 - Tables
SJM & SJII Series
Table 2-1a. Specifications and Features
60292AA
Ω
Weight with standard 3’ (0.9m) extension platform. Refer to Serial
Nameplate for specific applications.
Model 3015 3219 3220 3226
Weight 2200 lbs. 2430 lbs. 3739 lbs. 4660 lbs.
Ω
(998 kg) (1102 kg) (1696 kg) (2114 kg)
30”
Width
(0.76 m)
32”
(0.81 m)
67.0” 68.0”
Length
(1.7 m) (1.73 m)
88.5”
(2.24 m)
Platform
Size
28” x 64”
(0.71 x 1.63 m)
28” x 81”
(0.71 x 2.05 m)
21’ 25’ 26’ 32’
Working
(6.4 m) (7.6 m) (7.92 m) (9.75 m)
Platform 15’ 19’ 20’ 26’
Elevated (4.6 m) (5.8 m) (6.1 m) (7.92 m)
Platform 39.5” 39.0” 38.0” 44.0”
Lowered (1.00 m) (0.99 m) (0.97 m) (1.12 m)
Hinged 87.0”
Railing
N/A N/A
81.75”
(2.08 m)
(2.21 m)
Fixed 78.0” 79.079.25”
Height
Railing (1.98 m) (2.01 m) (2.01 m)
N/A
ANSI
CSA
Drive Height
CE
Full Full Full
18’
(5.5 m)
High Travel Speed
2 mph
(3.2 km/h)
Elevated
Drive Speed
0.65 mph
(1.05 km/h)
0.64 mph
(1 km/h)
0.66 mph
(1.1 km/h)
High Torque Drive
Speed
N/A
1.2 mph
(1.9 km/h)
1.33 mph
(2.14 km/h)
Lift time
(No Load)
21 sec. 30 sec. 23 sec. 42 sec.
Lower Time
(No Load)
29 sec. 40 sec. 40 sec. 39 sec.
Lift Time
(Rated Load)
23 sec. 33 sec. 28 sec. 56 sec.
Lower Time
(Rated Load)
19 sec. 29 sec. 27 sec. 30 sec.
Gradability 20% + 25%
12 x 4 x 8 16 x 4 x 8
Tires
Solid Rubber
