Table 1. Register Write-Allowed Masks
Address (Decimal) Mask (Hex)
00x00
10x00
20x00
30x00
40x00
50x00
60x1D
70x00
80x00
90x00
10 0x00
11 0x00
12 0x00
13 0x00
14 0x00
15 0x00
16 0x00
17 0x00
18 0x00
19 0x00
20 0x00
21 0x00
22 0x00
23 0x00
24 0x00
25 0x00
26 0x00
27 0x80
28 0xFF
29 0xFF
30 0xFF
*Note: See Figure 9 in the Si5338 data sheet for the correct usage of
registers 230, 241, and 246. These registers are not saved in the
register map or C code header file from ClockBuilder Pro.
