217 0xFF
218 0x00
219 0x00
220 0x00
221 0x00
222 0x00
223 0x00
224 0x00
225 0x00
226 0x04
227 0x00
228 0x00
229 0x00
230* 0xFF
231 0x00
232 0x00
233 0x00
234 0x00
235 0x00
236 0x00
237 0x00
238 0x00
239 0x00
240 0x00
241* 0xFF
242 0x02
243 0x00
244 0x00
245 0x00
246* 0xFF
247 0x00
Table 1. Register Write-Allowed Masks (Continued)
Address (Decimal) Mask (Hex)
*Note: See Figure 9 in the Si5338 data sheet for the correct usage of
registers 230, 241, and 246. These registers are not saved in the
register map or C code header file from ClockBuilder Pro.
