279 0x00
280 0x00
281 0x00
282 0x00
283 0x00
284 0x00
285 0x00
286 0x00
287 0xFF
288 0xFF
289 0xFF
290 0xFF
291 0xFF
292 0xFF
293 0xFF
294 0xFF
295 0xFF
296 0xFF
297 0xFF
298 0xFF
299 0x0F
300 0x00
301 0x00
302 0x00
303 0xFF
304 0xFF
305 0xFF
306 0xFF
307 0xFF
308 0xFF
309 0xFF
Table 1. Register Write-Allowed Masks (Continued)
Address (Decimal) Mask (Hex)
*Note: See Figure 9 in the Si5338 data sheet for the correct usage of
registers 230, 241, and 246. These registers are not saved in the
register map or C code header file from ClockBuilder Pro.
