319 MS2_SSUPP2[7:0]
320 MS2_SSUPP2[14:8]
321 MS2_SSUPP3[7:0]
322 MS2_SSUPP3[14:8]
323 MS2_SSUPP1[7:0]
324 MS2_SSUDP1[3:0] MS2_SSUPP1[11:8]
325 MS2_SSUDP1[11:4]
326 MS2_SSDNP2[7:0]
327 MS2_SSDNP2[14:8]
328 MS2_SSDNP3[7:0]
329 MS2_SSDNP3[14:8]
330 MS2_SSDNP1[7:0]
331 MS2_SSDNP1[11:8]
335 MS3_SSUPP2[7:0]
336 MS3_SSUPP2[14:8]
337 MS3_SSUPP3[7:0]
338 MS3_SSUPP3[14:8]
339 MS3_SSUPP1[7:0]
340 MS3_SSUDP1[3:0] MS3_SSUPP1[11:8]
341 MS3_SSUDP1[11:4]
342 MS3_SSDNP2[7:0]
343 MS3_SSDNP2[14:8]
344 MS3_SSDNP3[7:0]
345 MS3_SSDNP3[14:8]
346 MS3_SSDNP1[7:0]
347 MS3_SSDNP1[11:8]
Table 2. Register Summary (Continued)
Register 7 6 5 4 3 2 1 0
