MST6M181VG/MST6M182VG
LCD Television System-on-Chip
Preliminary Pin Diagram/Description and Mechanical Dimensions Version 0.2
- 2 - 8/29/2011
Copyright
2011 MStar Semiconductor, Inc. All rights reserved.
PIN DESCRIPTION
Analog Interface
Pin Name Pin Type Function Pin
HSYNC0 Schmitt Trigger Input
w/ 5V-tolerant
HSYNC / Composite Sync for VGA Input from channel 0 E4
VSYNC0 Schmitt Trigger Input
w/ 5V-tolerant
VSYNC for VGA Input from channel 0 F4
BIN0P Analog Input Analog Blue Input from Channel 0 E3
SOGIN0 Analog Input Sync On Green Input from Channel 0 E2
GIN0P Analog Input Analog Green Input from Channel 0 F3
GIN0M Analog Input Reference Ground for Analog Green Input from Channel 0 F2
RIN0P Analog Input Analog Red Input from Channel 0 F1
BIN1P Analog Input Analog Blue Input from Channel 1 H3
SOGIN1 Analog Input Sync On Green Input from Channel 1 H2
GIN1P Analog Input Analog Green Input from Channel 1 J3
GIN1M Analog Input Reference Ground for Analog Green Input from Channel 1 J2
RIN1P Analog Input Analog Red Input from Channel 1 J1
Analog Video Input/Output Interface
Pin Name Pin Type Function Pin
CVBS2 Analog Input CVBS (Composite) Video Input Channel 2 K1
CVBS1 Analog Input CVBS (Composite) Video Input Channel 1 K2
CVBS0 Analog Input CVBS (Composite) Video Input Channel 0 L1
VCOM Analog Input CVBS Input Reference Ground L2
CVBSOUT Analog Output CVBS (Composite) Video Output Channel M1
Analog Audio Input/Output Interface
Pin Name Pin Type Function Pin
I2S_OUT_WS I/O w/ 5V-tolerant Word Select Output; 4mA driving strength /
Universal Asynchronous Receiver 2 (UART2_RX)
T8
I2S_OUT_SD I/O w/ 5V-tolerant Audio Serial Data Output; 4mA driving strength /
Universal Asynchronous Transmitter 2 (UART2_TX)
P8
SPDIFI Input w/ 5V-tolerant S/PDIF Audio Input /
Pulse Width Modulation Output; 4mA driving strength
(PWM3)
P9
SPDIFO Output S/PDIF Audio Output; 4mA driving strength T9
