MST6M181VG/MST6M182VG
LCD Television System-on-Chip
Preliminary Pin Diagram/Description and Mechanical Dimensions Version 0.2
- 3 - 8/29/2011
Copyright
2011 MStar Semiconductor, Inc. All rights reserved.
Pin Name Pin Type Function Pin
I2S_OUT_MCK Output w/ 5V-tolerant Audio Master Clock Output R8
I2S_OUT_BCK Output w/ 5V-tolerant Audio Bit Clock Output R9
AUL0 Analog Input Audio Line Input Left Channel 0 M2
AUR0 Analog Input Audio Line Input Right Channel 0 N1
AUL1 Analog Input Audio Line Input Left Channel 1 N2
AUR1 Analog Input Audio Line Input Right Channel 1 P1
AUL2 Analog Input Audio Line Input Left Channel 2 P2
AUR2 Analog Input Audio Line Input Right Channel 2 R1
AUL3 Analog Input Audio Line Input Left Channel 3 M3
AUR3 Analog Input Audio Line Input Right Channel 3 N3
AUVRP Analog Output Positive Reference Voltage for Audio ADC L4
AUVAG Analog Output Reference Voltage for Audio Common Mode L3
AUOUTL1 Analog Output Main Audio Output Left Channel 1 N4
AUOUTR1 Analog Output Main Audio Output Right Channel 1 P3
AUOUTL0 Analog Output Main Audio Output Left Channel 0 R2
AUOUTR0 Analog Output Main Audio Output Right Channel 0 T2
Mini-LVDS Interface
Pin Name Pin Type Function Pin
LLV5M Output Mini-LVDS L-Link Channel 5 Negative Data Output P10
LLV5P Output Mini-LVDS L-Link Channel 5 Positive Data Output R10
LLV4M Output Mini-LVDS L-Link Channel 4 Negative Data Output P11
LLV4P Output Mini-LVDS L-Link Channel 4 Positive Data Output R11
LLV3M Output Mini-LVDS L-Link Channel 3 Negative Data Output T11
LLV3P Output Mini-LVDS L-Link Channel 3 Positive Data Output P12
LLV2M Output Mini-LVDS L-Link Channel 2 Negative Data Output P13
LLV2P Output Mini-LVDS L-Link Channel 2 Positive Data Output R13
LLV1M Output Mini-LVDS L-Link Channel 1 Negative Data Output P14
LLV1P Output Mini-LVDS L-Link Channel 1 Positive Data Output R14
LLV0M Output Mini-LVDS L-Link Channel 0 Negative Data Output T14
LLV0P Output Mini-LVDS L-Link Channel 0 Positive Data Output T15
LLVCKM Output Mini-LVDS L-Link Negative Clock Output T12
LLVCKP Output Mini-LVDS L-Link Positive Clock Output R12
RLV5M Output Mini-LVDS R-Link Channel 5 Negative Data Output R15
RLV5P Output Mini-LVDS R-Link Channel 5 Positive Data Output R16
