MST6M181VG/MST6M182VG
LCD Television System-on-Chip
Preliminary Pin Diagram/Description and Mechanical Dimensions Version 0.2
- 4 - 8/29/2011
Copyright
2011 MStar Semiconductor, Inc. All rights reserved.
Pin Name Pin Type Function Pin
RLV4M Output Mini-LVDS R-Link Channel 4 Negative Data Output P15
RLV4P Output Mini-LVDS R-Link Channel 4 Positive Data Output P16
RLV3M Output Mini-LVDS R-Link Channel 3 Negative Data Output N14
RLV3P Output Mini-LVDS R-Link Channel 3 Positive Data Output N15
RLV2M Output Mini-LVDS R-Link Channel 2 Negative Data Output M16
RLV2P Output Mini-LVDS R-Link Channel 2 Positive Data Output L16
RLV1M Output Mini-LVDS R-Link Channel 1 Negative Data Output N10
RLV1P Output Mini-LVDS R-Link Channel 1 Positive Data Output N11
RLV0M Output Mini-LVDS R-Link Channel 0 Negative Data Output N12
RLV0P Output Mini-LVDS R-Link Channel 0 Positive Data Output N13
RLVCKM Output Mini-LVDS R-Link Negative Clock Output M14
RLVCKP Output Mini-LVDS R-Link Positive Clock Output M15
TCON Interface
Pin Name Pin Type Function Pin
POL Output Polarity Control Single E15
SOE Output Source Output Enable H15
GSP/
VST
Output Gate Start Pulse for LTD Panel /
Vertical start pulse for GIP Panel
H14
GCLK6 Output Gate Clock for GIP Panel L15
GCLK5 Output Gate Clock for GIP Panel K15
GCLK4 Output Gate Clock for GIP Panel G16
GSC/
GCLK3
Output Gate Shift Clock for LTD Panel /
Gate Clock for GIP Panel
J15
GOE/
GCLK2
Output Gate Clock for GIP Panel /
Gate Output Enable for LTD Panel
E16
GSP_R/
GCLK1
Output Right Gate Start Pulse for LTD Panel /
Gate Clock for GIP Panel
J14
SCAN_BLK1 Output Scan Backlight Control Signal 1 F14
SCAN_BLK Output Scan Backlight Control Signal E14
OPT_N Output The Output Pin to Indicate Reverse State G15
OPT_P Output The Output Pin to Indicate Reverse State F16
FLK3 Output Gate Modulation Signal H16
FLK2 Output Gate Modulation Signal L14
FLK Output Gate Modulation Signal J16
