42
BREW TANK COMPONENTS
ITEM NO. PART NUMBER DESCRIPTION
1 44000-36080 Hex Nut, Element Mount
2 44000-36070 Lock Washer, Element Mount
3 30000-20130 Element, Brew, 600 Watt, 220V
4 30000-20140 Gasket, Element, Teflon
5 30000-20251 Thermostat, 110C
6 44000-36310 Screw, Socket Head Cap, M4 thread, 5mm Length, .7mm Pitch, Stainless
7 30000-20153 Valve, 3-way, Flange Mount, 2mm, 24v
8 42000-34300 Fitting, Medium- Pressure, Threaded Pipe, 1/8 Pipe Size, Solid Hex-Head Plug, Brass
9 15005-16061 Brew Tank, Slayer Steam
10 10000-16061 Giggleur, 0.7mm, V3
11 46000-10010 O-Ring for Jet Holder, 1 x 3
12 42000-34560 Fitting, 90 Deg Elbow for 1/4" Tube OD x 1/8" NPTF - M, Brass
13 44005-10012 18-8 Stainless Steel Socket Head Screw M6 x 1 mm Thread, 12 mm Long
14 44000-36110 Lock Washer, Tank Mount
15 46000-53040 Washer, Flat, M7 Screw Size, 14mm OD, 1.4mm-1.8mm Thick
SLAYER STEAM X USER MANUAL V1.1 | SEPTEMBER 2019
