Slayer Professional Series - Water Inlet Manifold Assembly

43
SLAYER STEAM X USER MANUAL
Water Inlet Manifold Assembly
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 46000-50110 EXPANSION VALVE 1
2
46000-50150 COPPER GASKET 1/4 NPT 1
3
42004-34510 TRANSDUCER ELBOW 1
4
42000-34500 1/8 NPT X 1/4 COPPER COMP. 4
5
10005-03050 WATER INLET MANIFOLD 1
6 42000-34300 BLEED SCREW PLUG 1
7
46005-34620
1 WAY VALVE 1
8
42000-10010 3/8 WATER INLET FITTING 1
9
42004-34500 PRV ELBOW 1
1
2
3
4
5
6
7
8
9
99005-03050
WWW.SLAYERESPRESSO.COM
206-284-7171
NAME
