STEAM WAND COMPONENTS
ITEM NO. PART NUMBER DESCRIPTION
1 46000-50030 O-Ring for Steam Tip, 1.5 x 6
2
46000-50340 Steam Tip, 1.0mm, #0
46000-50341 Steam Tip, 1.1mm, #1
46000-50342 Steam Tip, 1.2mm, #2
46000-50343 Steam Tip, 1.3mm, #3
46000-50344 Steam Tip, 1.4mm, #4
46000-50345 Steam Tip, 1.5mm, #5
3 46005-53170 Steam Wandom Grip - Slayer Branded
4 10000-10011 Plug, JIS, Female, 1/8", for 3-Way Valve
5 46000-53050 O-Ring for Peek Steam Valve Bushing
6 30000-20152 Steam X, 3 Way Solenoid, 24VDC COIL, 1/4" NPT
7 42000-34680 Fitting, Easy-Align, Compression Tube, Elbow for 5/16" Tube OD x 1/4 - M Pipe, Brass
8 46005-53010 Rear Block for Steam Assembly
9 46005-53030 Compression Spring for Steam Wand
10 46000-53070 Gasket for Steam Valve Brew Actuator, 27mm, Teflon
11 46000-53040 Washer, Flat, M7 Screw Size, 14mm OD, 1.4mm-1.8mm Thick
12 46005-53060 Bushing, 15 X 10.5mm Peek Plastic
13 46005-53110 Steam Seal, Peek Plastic
14 10005-10002 Steam, Wand Socket
15 10005-10008 Steam and Hot Water Lock Nut
16 40005-50330 Steam Wand, #3 Tip, Slayer Steam
SLAYER STEAM X USER MANUAL V1.1 | SEPTEMBER 2019
