Slayer Professional Series - Barista Dashboard Display Assembly

49
SLAYER STEAM X USER MANUAL
99005-30020
WWW.SLAYERESPRESSO.COM
206-284-7171
NAME
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 20005-10003 DISPLAY END LEFT 1
2
44005-10020 RAIL CLIP SCREW 6
3
13005-30052
13005-20052
DISPLAY COVER, 3GP 1
4
20005-10002 DISPLAY ATTACHMENT 2
5
13005-30053
13005-20053
DISPLAY COVER LOWER PANEL 3GRP
DISPLAY COVER LOWER PANEL 2GRP
1
6
44005-10130 PANEL MOUNT SCREW 6
7
20005-10000 DISPLAY END RIGHT 1
8
93655A459 THREADED SPACER 2
9
26005-10000 DISPLAY GLASS 3
10
10005-03010 ENCODER KNOB 3
11
92605A102 SET SCREW 3
12
20005-10001 FACE PLATE 3
13
30005-60110 DISPLAY 1
14
30005-20100 OPTICAL ENCODER 3
2 4
8
3
5
6
7
14131110 129
1
Barista Dashboard Display Assembly
