Slayer Professional Series - Drain Manifold Assembly

45
SLAYER STEAM X USER MANUAL
Drain Manifold Assembly
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 42000-34560 1/4 COMP 90 DEG 1
2
13005-30018
13005-20018
DRAIN MANIFOLD, 3GRP
DRAIN MANIFOLD, 2GRP
1
3
42000-34180 1/8 NPT HEX NIPPLE 4
4
42000-34500 1/8 NPT X 1/4 COPPER COMP. 3
5
42005-10000 5/16 HOSE BARB
2
6
42000-34220
PUSH CONNECT FITTING
1
6
5
4
2
3
1
99005-30018
