STEAM ACTUATOR COMPONENTS - RIGHT/LEFT
ITEM NO. PART NUMBER DESCRIPTION
1 44000-36102 Bolt, Hex Head, 1/4-20 x 3/4
2 44005-10320 Plastic Steam Actuator Disk Spring
3 99015-10004 Left Actuator Handle Assembly
4 44000-36260 Actuator, Steam, Stop Bolt, Short
5 46005-01010 Teflon Gasket
6 13005-30045 Chassis Brace, Left Front, Steam
7 10005-02010 Steam Actuator Bushing, Small
8 46005-10026 18-8 Stainless Steel Thin Nylon-Insert Locknut, 1/4"-20 Thread Size, packs of 50
9 99005-30036 Complete Duratex Steam Actuator Handle
10 99015-10003 Right Actuator Handle Assembly
11 44000-36310 Screw, Socket Head Cap, M4 thread, 5mm Length, .7mm Pitch, Stainless
12 13005-30009 Chassis Brace, Right Front, Steam
13 46003-50061 Slayer Steam Actuator Magnet, 5/16" x 1/8"
14 10005-03090 Magnetic Switch Mount
15 44005-10350 18-8 External-Tooth Lock Washer for M4 Screw
16 44005-10340 18-8 Phillips Rounded Head Screws M4 x 0.7 mm Thread 10 mm Long
17 30005-20031 Barrel Switch w/ Molex, N/C
SLAYER STEAM X USER MANUAL V1.1 | SEPTEMBER 2019
