40
BREW GROUP HEAD COMPONENTS
ITEM NO. PART NUMBER DESCRIPTION
1 44000-36152 Stainless Steel Slotted Oval Head Screws, 1/4"-20 Thread Size, 1/2" Long, Polished Head
2 44000-50210 Insert Nut for Brew Handle, Stainless
3 44000-50190 Spacer for Group Handle
4 99005-56500 Brew Actuator Assembly, Slayer Steam, Duratex
5 44000-50260 Screw, Group Cover Mount, Polished Head
6 20000-16080 Group Cover
7 10000-16210 Spacer
8 44000-16220 Washer, Fender, 3/8 x 1.25 x 0.05, Stainless
9 99003-50051 Tongue Assembly
10 44000-36330 Screw and Washer for Magnet and Power Supply
11 30000-20032 Mag Switch, N/C, pinned
12 42000-34300 Fitting, Medium- Pressure, Threaded Pipe, 1/8 Pipe Size, Solid Hex-Head Plug, Brass
13 46000-50270 Stand O for Group Cover
14 99004-16100 Brew Cap With Magnet
15 46000-50100 Gasket for Group Cap, Paper
16 46000-50090 O-Ring, FKM, 70 A, Group Cap
17 20000-56010 Bayonet Ring
18 46000-50080 Diuser Screw, Stainless
19 46000-50073 Nano Coated Shower Screen - Custom Slayer
20 46000-56091 Gasket for Group Head, 6.1mm
21 44000-36000 Spacer for Inverted Mag Switch
22 30000-20042 Mag Switch, N/O, pinned
23 44000-36140 Screw and Washer for Inverted Magnet
24 44000-56000 Screw, Socket Head Cap, M8 Thread, 55mm Length, 1.25mm Pitch, Stainless
25 30005-20081 Thermistor, Steam - 3K3 NTC
26 10000-16161 Stem for Brew Actuator, V3
27 46000-50240 Belleville Disc Spring for Valve Assembly, Stainless
28 10000-16200 Bushing, Oilite
29 46000-53070 Gasket for Steam Valve Brew Actuator, 27mm, Teflon
SLAYER STEAM X USER MANUAL V1.1 | SEPTEMBER 2019
