52
DRAIN CIRCUIT
ITEM NO. PART NUMBER DESCRIPTION
1 40005-32100 Tube, Ball Valve to Drain
2 42000-34500 Fitting, 1/4" Tube OD x 1/8" NPTF - M, Brass
3 42000-50290 Ball Valve, 1/8" NPT
4 42000-34560 Fitting, 90 Deg Elbow for 1/4" Tube OD x 1/8" NPTF - M, Brass
5 40005-32060 Hot Water to Mix Valve Tube, Slayer Steam
6 42000-34300 Fitting, Medium- Pressure, Threaded Pipe, 1/8 Pipe Size, Solid Hex-Head Plug, Brass
7 40000-32150 High-Temperature Silicone Rubber Tubing, Soft, 5/16" ID, 7/16" OD, 1/16" Wall, White - Per Inch
8 44000-36290 Spring Clip for Single Group Drain, Small
9 42005-10000 Fitting, Barbed Hose, Adapter for 5/16" Hose ID x 1/8" NPTF - M Pipe, Brass
10 40005-32120 Ball Valve to Drain Tube
11 40000-32180 EPDM Rubber Tubing 5/16" ID, 7/16" OD - Per Inch
12 42000-34220 Fitting, Tube, Hex Socket Adapter for 1/4" Tube OD, 1/8" NPT M, Polybutylene & Nickel
13 40000-32050 Extreme-Temp Tubing, Teflon, Semi-Clear White 1/8" ID, 1/4" OD - Per Inch
14 40005-32120 Ball Valve to Drain Tube
15 40005-32050 Brew Tank to Ball Valve Tube
16 44005-10012 18-8 Stainless Steel Socket Head Screw M6 x 1 mm Thread, 12 mm Long
17 44000-36110 Lock Washer, Tank Mount
18 46000-53040 Washer, Flat, M7 Screw Size, 14mm OD, 1.4mm-1.8mm Thick
19
13005-20018 Drain Manifold, Steam, 2 Group
13005-30018 Drain Manifold, Steam, 3 Group
20 40000-32060 Worm-Drive Hose Clamp, Non Slip Screw 1/2" to 1-1/16" Clamp Diameter Range, 9/16" Band Width
21 40000-32170 3-A Sanitary Clear PVC Vacuum Tubing 5/8" ID, 7/8" OD, 1/8" Wall Thickness
SLAYER STEAM X USER MANUAL V1.1 | SEPTEMBER 2019
