Slayer Professional Series User Manual

54
WATER FILL CIRCUIT
ITEM NO. PART NUMBER DESCRIPTION
1 42000-34560 Fitting, 90 Deg Elbow for 1/4" Tube OD x 1/8" NPTF - M, Brass
2 10005-03050 Water Inlet Manifold, Steam
3 42000-34300 Fitting, Medium- Pressure, Threaded Pipe, 1/8 Pipe Size, Solid Hex-Head Plug, Brass
4 42004-34510 Fitting, Medium-Pressure, Threaded Pipe, 1/4 Pipe Size, M x F Elbow, Brass
5 46000-50150 Gasket ,1/4", Copper for Anti Suction, Level Probe, Expansion Valve V3/Steam
6 46000-50110 Expansion Valve
7 30005-21200 Flow Meter
8 42000-34702 Fitting, Easy-Align, Compression Tube, Elbow for 1/4" Tube OD x 1/4 - M Pipe, Brass
9 42000-34700 Fitting, Easy-Align, Compression Tube, Straight Adapter for 1/4" Tube OD x 1/4 - M Pipe, Brass
10 40005-32110 Flow Meter Tube
11 40005-32010 Water Inlet Tube, Slayer Steam, Group 3
12 40005-32020 Water Inlet Tube, Slayer Steam, Group 2
13 40005-32030 Water Inlet Tube, Slayer Steam, Group 1
14 42000-34500 Fitting, 1/4" Tube OD x 1/8" NPTF - M, Brass
15 44000-10010 Brass Nut - 3/8 BSPP
16 44000-36360 Washer, External Tooth, Star, 3/8
17 30000-20195 Solenoid Valve, 2-Way, 1/8" NPT, 2.5mm, 24v Steam Tank Fill
18 40005-32040 Steam Fill Tube, Long
19 42000-10010 Extension, Fitting, 3/8"
20 42004-34500 Fitting, Medium-Pressure, Threaded Pipe, 3/8 Pipe Size, M x F Elbow, Brass
21 46005-34620 Check Valve, 3/8" NPT, Slayer Steam
SLAYER STEAM X USER MANUAL V1.1 | SEPTEMBER 2019
