STEAM CIRCUIT
ITEM NO. PART NUMBER DESCRIPTION
1 40005-32210 Left Steam Out Tube, Steam X
2 40005-32170 Steam Manifold Tube
3 42000-34500 Fitting, 1/4" Tube OD x 1/8" NPTF - M, Brass
4 46000-50150 Gasket ,1/4", Copper for Anti Suction, Level Probe, Expansion Valve V3/Steam
5 46000-50140 Anti-Suction/Vacuum Valve, 1/4"
6 46000-50120 PRV, 2.5 Bar
7 46000-50130 Gasket for PRV, 3/8", Copper
8 10005-03030 PRV Manifold, Steam
9 40015-32002 Honeywell Pressure Transducer Tube
10 44000-36220 Fitting, 45 Degree, Flared, Short Nut for 1/4" Tube OD, Brass
11 99005-17000 Steam Transducer Assembly
12 40005-32220 Right Steam Out Tube, Steam X
SLAYER STEAM X USER MANUAL V1.1 | SEPTEMBER 2019
