Ref : 26702 15 07/01/15
PART 4 : Adjustment of the door operation
To make the door’s operation even more accurate, you can also
trigger on speeds (F), acceleration and deceleration ramps (R),
torques (U) and the travels (C).
OPERATING DIAGRAMS
OPERATING PARAMETERS WITH MOBILE SKATE (TYPE = MOB1)
RA-O
RD-O RD-F
RA-O RD-F
DURO DURF
OPERATING PARAMETERS WITH FIXED SKATE (TYPE = FI)
RA-O
RD-O RD-F
RA-O
DURO DURF
OPERATING PARAMETERS IN FRONT OF SWINGING DOOR (TYPE = BATT)
RD-O RD-F
DURO DURF
U2-O U2-F
FP-O FP-F
<------- CS-F ------->
FS-O RA-F FS-F
U1-S U-FR FF-O U-FR FF-F U1-S
U1-O U1-F
<----- CS-O -----> <-- CL-O --> < CL-F
Skate travel Panels travel (Clea opening) Panels travel (Clea opening) Skate travel
FP-O FP-F
U2-O U2-F
FS-O RA-F
U-FR FF-F
U1-O U1-F
<----- CS-O------
<-- CL-O -->
--- CL-F ---
U1-S U-FR FF-O
FF-F
Panels travel (Clea opening) Panels travel (Clea opening)
FP-O FP-F
U2-O U2-F
RA-O RA-F
U-FR FF-O U-FR
U1-O U1-F
<-- CL-O -->
--- CL-F ---
Panels travel (Clea opening) Panels travel (Clea opening)
CHANGING A PARAMETER
Scroll the menus by successively pressing ,
and select PARA by pressing
.
Scroll the parameters with
To read the value, press
To change value, press
To save the new value, press
To exit parameter setting, simultaneously press
and
