SPECIAL CASE OF A DOUBLE OPENING TRAVEL
The command modes CMD2/4/6/8 are specific to
double-travel door adjustments (complete or partial
opening of the door on request according to the open or
intermediate open command)
CMD2 : Learning the intermediate travel
To start this command, the learning of the total travel must already be
done (CMD1). Before starting CMD2, the door must be in the closed
position.
The card orders the intermediate end stop and triggers an open cycle and
then a close cycle at the end of which the encoder’s absolute value is
saved as the reference intermediate travel.
Warning : for a new learning of the total travel, the learning of
the partial travel must be repeated.
CMD4 : Direct motor command (intermediate opening)
The CMD4 mode is the same as the CMD3 mode, but actuates the
intermediate end stop and operates in partial travel.
To quit this mode, press
.
This mode activates only the motor and not the card outputs.
CMD6 : Intermediate openings and closings with and
The CMD6 mode is the same as the CMD5 mode, but the key actuates
the intermediate end stop and starts a partial open cycle. This mode is
only accessible if the intermediate learning (CMD2) was done.
To quit this mode, press
.
This mode does not activate the shock and limit swich stop
signals
CMD8 : Intermediate open/close cycles
The CMD8 mode is the same as the CMD7 mode, but the openings are
made on the partial travel by activating the intermediate end stop. This
mode is only accessible if the intermediate learning (CMD2) was done.
To quit this mode, press
.
This mode does not activate the shock and limit switch stop
signals
Note : the CMD commands are executable in inspection mode
and in normal mode
