Ref : 26702 17 07/01/15
VALUE RANGE TABLE
CAN Car door number PrtE 1, 2 ou 3
CAN Communication speed bAud bauds
Motor type Motr ASYn, bruS
Fault stack Err 0 à 10
Number of cycles in thousands CyCL x 1000
Pre-set table choice Pini 01 à 99
Multifunction relay no. 1 rMF1 buZZ, butE, CAME, Vent
Multifunction relay no. 2 rMF2 butE, CAME, Vent, buZZ
Operator type tyPE Mobi, Fi, bAt
Car Cell connected CELL non, oui
Glazed door Vitr non, oui
Motor direction Smot dir, inv
Travel end stop direction FdC nF, nO
Shock signal direction CHoC nO, nF
Shock management mode ModE MAi1, MAi2, Escl
Hold under voltage during opening Msto yes, no
Hold under voltage during closing MstF yes, no
Opening Cruise Frequency FP-O 2 to 50 Hz
End of Opening Frequency FF-O 2 to 5 Hz
Opening Skate Frequency FS-O 3 to 7 Hz
Opening Handling Frequency FM-O 5 to 10 Hz
Closing Cruise Frequency FP-F 2 to 50 Hz
End of Closing Frequency FF-F 2 to 5 Hz
Closing Skate Frequency FS-F 3 to 7 Hz
Closing controller Frequency FM-F 5 to 10 Hz
Opening Acceleration Ramp RA-O 1 to 3 s
Opening Deceleration Ramp RD-O 1 to 3 s
Opening Acceleration Ramp RA-F 1 to 3 s
Opening Deceleration Ramp RD-F 1 to 3 s
Slow Closing Travel CL-F 1 to 150 Pts
Slow Opening Travel CL-O 1 to 200 Pts
Braking Torque u-Fr 40 to 100 Volts
Opening Hardness durO 0 to 100 %
Closing Hardness durF 0 to 100 %
Min Opening Voltage U1-O 20 to 70 Volts
Max Opening Voltage U2-O 70 to 180 Volts
Min Closing Voltage U1-F 20 to 50 Volts
Max Closing Voltage U2-F 50 to 140 Volts
Min Skate Voltage U1-S 20 to 50 Volts
Max Skate Voltage U2-S 50 to 180 Volts
Opening Skate Travel CS-O 10 to 70 Pts
Closing Skate Travel CS-F 10 to 50 Pts
Open Order Wait Time tA-O 15 to 90 min
Cruise Frequency Reduction R-FP 0 to 50 %
