Ref : 26702 9 07/01/15
Terminal n° Assignment
Ph, N, T Mains power supply
L1, L2, L3, T Motor connection
5, 6 Safety chain connection
7, 8, 9, 10 Door contacts connection
14, 15 Shock signal
16, 17 Closing limit switch stop signal
18, 19 Opening limit switch stop signal
25 + 12 VDC
26, 27 NC (normally closed) Cell input
28 Inspection NO (normally opened) command input
29 Nudging NO Command input (forced closing)
30 Closing NO command input
31 Intermediate Opening NO command input
32 Complete opening NO command input
33 Common 0V of the commands
PART 2 : Configuration according to the controller
Scroll the menus by successively pressing
,
and select PARA by pressing
.
Scroll the parameters with
To read the value, press
To change the value, press
To save the new value, press
SETTING OF THE MANDATORY PARAMETERS
Display order of the parameters :
→ MSTF Hold under voltage closing OUI(YES) /NON(NO)/DEPL Set in Factory
→ MSTO Hold under voltage opening OUI (YES)/NON(NO) Set in Factory
→ MODE
Operating mode : ESCL/MAI1/MAI2
→ CHOC Shock contact direction / Controller : NO or NF
→ FdC Limit switch contact direction / Controller : NO or NF
→ SMOT Motor rotating direction DIR/INV Set in Factory
